REDFLUID Fittings & valves manufacturer

QUALITY

WE HAVE THE BEST STANDARDS & CERTIFICATIONS

CE

ATEX

ISO 9001

GOST TR CU

REDFLUID

FITTINGS AND VALVES FOR YOUR REQUIREMENTS
NPT BSP BSPT SW BW SCH ISO SAE DIN FERRULE NO LIMIT...

Our standard production programme of valves and fittings for instrumentation, hydraulic or pneumatic services.

Redfluid also manufactures special valves and fittings according to drawings or samples and in various types of materials.

Our experience and wide knowledge are free available to help our customers.

  • Stainless steel

    316, 316L, 304, 304L

  • CARBON STEEL

    A105, F1, A106/B, ST52.3, F11, F22 ...

  • EXOTIC ALLOYS

    SUPERDUPLEX, DUPLEX, ALLOY20, HASTELLOY, 904/L, MONEL ...

  • BRASS, PTFE

    OTHER MATERIALS LIKE BRASS, PVA, PTFE...

HIGH & LOW TEMPERATURE FITTINGS AND VALVES

FROM CRYOGENIC TEMPERATURES UP TO HIGH TEMPERATURES OF 800ºC

HIGH PRESSURE FITTINGS AND VALVES

OUR PRESSURE RANGE CAN FROM VACUUM UP TO 2500 BAR

REDUCED OR FULL BORE VALVES

Reduced and Full Bore Valves

CLEAN & DEGREASED

FOOD INDUSTRY STANDARDS FOR CLEANING FITTINGS AND VALVES

STANDARD PRODUCTION

Our standard production programme of valves and fittings for instrumentation, hydraulic or pneumatic services
Uploaded image

3000 and 6000 PSI fittings

The fittings are made of forged or bar steel, according ANSI B.16.11. standard.
Carbon Steel ASTM A 105 Gr-II – Stainless steel (AISI-316/316L) – Duplex, superduplex. F1, F11, F22, F91.
Uploaded image

Ball valve

Different connections BSP. NPT, SW, BW Flanged SAE J1926 and DIN 2353. Fire Safe BS6755, Antistatic device. Tests as per API 6D and API 598.
High pressure ball valves up to 500 bar and 230oC according different seats.
Uploaded image

BW Fittings and Flanges

Flanges ANSI B 16.5 and DIN. Fittings BW SCH 40, 80 &160 B16.9 AND 1516.28
Also we offer: BRITISH STANDARD 3293 API STANDARD 605 B 16.47 B MSS STANDARD PRACTICE SP-44 B 16.47 A
Uploaded image

Check valve

Chick valves with free flow in one way and blockead in the oteher way for preventing revese flow and stopping back pressure in hydraulic and pnematic circuits.
In the valve, there is an automatic lock system with a piston and a spring.
Uploaded image

Condensing pots

The two different standard condensing pots are supplied with half couplings, threaded or socket weld, according to the following: – NPT threads, ANSI B2.1 – SW, ANSI B16.11 Couplings are 3000 psi.
Manufactured in two standard versions – Series AC. In carbon steel – SS Series. Type 316/316L stainless steel or A335 P11.
Uploaded image

Distributors

Redfluid high pressure Distribution Manifolds fulfil the need for a specific manifold working at instrument pressures. Designed in conjunction with our customers’ requirements.
316 Stainless Steel 304 Stainless Steel Carbon Steel Monel Hastelloy Duplex SuperDuplex
Uploaded image

Drain plug

Plugs for manual drain, suitable for installation in pots and condensate separation tanks.
Opening with a screw or handwheel with safety packing system. Both models are available in different sizes: 1/8 , 1/4 and 1/2 in NPT and BSPT threads. PN: 255 Bar
Uploaded image

Hydraulic hoses

Customized tubes and hoses as well as a wide variety of accessory components with different connections.
Uploaded image

Gauge valve

Valves for isolation and venting gauges, manostats and other instrumentation. Standard versions with vent and/or test flange. Working pressures up to 400 Bar.
Connection sizes in 1/4″ and 1/2″ male or female NPT or BSP threads. Materials in carbon steel, stainless Steel 316, duplex, superduplex and brass.
Uploaded image

Low pressure fittings

Low pressure fittings push in, push on, and single ferrule connection.
Uploaded image

MANIFOLDS

From the simplest 1 way – 1 valve to the most complex 2-way and 5-valve series.
2-valve manifolds are used in one-level pressure applications while 3 and 5-valve manifolds are usually used for differential pressure applications
Uploaded image

Minifluid

Miniature needle valves for low and medium pressure suitable for oil and compressed air.
Manufactured in brass. Threated and tubing ends up to 1/2”. Working pressure up to 64 bar and 100oC.
Uploaded image

Minor valve

Needle valves designed for panel mounting. The valve design permits a precision regulation of the flow and obtains an outlet flow without pulsations. Because of their high performance they are suitable for control panel.
Dimensions from 1/8” to 1/2” in straight and angle pattern. The connectors can be male, female, double ferrule compression fitting for tubing or mixt.
Uploaded image

Needle valve

Needle regulating valves suitable for instrumentation circuits and generally high pressure lines up to 4″ diameter.
Different connections, NPT (ANSI B2.1), BSPP (DIN 259), SW (ANSI B16.11); BW, SW OD, Flanged, Mixed. Various materials available from Carbon Steel, 316/316L Stainless, Brass, Duplex, Superduplex, Hastelloy, Monel among others.
Uploaded image

Piston valve

Quick opening valves to isolate manometers and pressure gauges for low pressure pipelines.
The instrument comes back to zero smoothly thanks to the design of the valve. Threaded connections 1⁄2”: – NPT, as per ASME B1.20.1 – BSPP, British Standard Pipe Parallel , as per DIN 259, ISO 228/1 Materials: Manufactured in brass with NBR O rings and Steel spring.
Uploaded image

Pressure damp

Pulsation dampeners for instrumenta- tion, working pressure up to 400 Bar. 1/4” and 1/2” threaded connections. The regulation is performed by a high-preci- sion screw that can adjust the pressure. Versions for low and high pressure.
Three standard materials are available: Serie AC. Carbon Steel UNE 36011 Serie SS. Stailnes Steel 316 Serie LA. Brass DIN17600 *Only for low pressure NBR packing (NBR) up to 100 oC (212 oF). Optional could be supplied with viton (FPM) up to 200 oC (329 oF)
Uploaded image

Quick coupling

Quick couplings for hydraulic services up to 300 bar. Easy single handed connection and disconnection.
Threaded connections up to 2”. With check valve in one or both sides. Manufactured in a different range of materials and as per ISO 7241-1.
Uploaded image

Single ferrule fittings

Cone Sealing Couplings to DIN 2353 / DIN EN ISO 8434-1
Uploaded image

Syphones

The siphons are protective elements that are mounted between the instrumentation and the process. Avoid direct contact of aggressive fluids that could damage the instruments.
The syphon acts as a thermal barrier to dissipate the heat and reduce whiplash caused by the fluid. They are made of seamless steel pipe , carbon steel or stainless steel and in diameters of 1/4 ” , 3/8 ” and 1/2 ” and thicknesses to ANSI B36.10 and B36.19
Uploaded image

Threaded fittings

Adaptors – BSP – Metric – NPT -Taper – JIC – SAE
Uploaded image

Twin ferrule fittings

Double ring compression fittings for tube. Compatible with Swagelok design.
Those fittings are designed for a wide range of leak- free application including gas leak proof and vacuum service. Each Redfluid double ferrule ittings consists of four precision engineered parts, the body a front ring a back ferrule and a tightening nut all designed to provide secure leak proof joints
Uploaded image

U BOLTS

Standard Serie, Heavy Serie, Instrumentation and DIN 3570
Standard version is in carbon steel with zinc plating, stainless steel 304 or 316. On request, superduplex, duplex, 904 among others

CONNECTIONS

OUR FITTINGS AND VALVES CAN HAVE ANY CONNECTION AS PER YOUR REQUIREMENTS
